Instrument Air-Gas Assemblies (1/4 - 1/2 Inch)
Protect your equipment and sensitive instruments from water, oil, and dirt with our high-efficiency instrument filters, engineered to remove contaminants at 99.99% efficiency down to 0.01 micron.
Notice: Trying to get property 'ID' of non-object in C:\sites\ufs\wp-content\themes\automize\woocommerce\single-product\ask-question.php on line 28
Notice: Trying to get property 'post_title' of non-object in C:\sites\ufs\wp-content\themes\automize\woocommerce\single-product\ask-question.php on line 28
Error: Contact form not found.
| PRODUCT FEATURES / BENEFITS |
| s Rugged, 100% Machined Anodized Aluminum Construction |
| s Remove 99.99% of Oil, Water, & Solids From Compressed Air & Other Gases |
| s High Efficiency Microfiber Elements |
| s Capture Dirt, Coalesce Liquids |
| s Instrument Air Filters |
| s Protected Air Actuated Valves |
| s Paint Spray Booths |
| s Fuel Gas Filter Metering |
| s Natural Gas Filtration |
| PRODUCT FEATURES / BENEFITS |
| s Rugged, 100% Machined Anodized Aluminum Construction |
| s Remove 99.99% of Oil, Water, & Solids From Compressed Air & Other Gases |
| s High Efficiency Microfiber Elements |
| s Capture Dirt, Coalesce Liquids |
| s Coalescing and Pleated Glass Particulate Filter Elements Available |
| s Instrument Air |
| s Food Processing Systems |
| s CNG Filtration |
| s Air Dryer Protection |
Description
Protect your equipment and sensitive instruments from water, oil, and dirt with our high-efficiency instrument filters, engineered to remove contaminants at 99.99% efficiency down to 0.01 micron. The 360 Series coalescing filters feature expanded liquid-holding capacity and can be equipped with optional high-volume automatic float drains (operational above 12 psi) and highly sensitive differential pressure indicators covering a 2–16 psi range. Our all-aluminum housings (suffix “A”), rated to 500 PSIG, make the 360A Series an ideal solution for CNG fuel gas filtration.
The 370 Series coalescing filters provide increased liquid-holding capacity and are available with optional high-volume automatic float drains (operational above 12 psi) and differential pressure indicators sensitive within the 2–16 psi range. Ideal for higher flow rate point-of-use applications. Our all-aluminum housings (suffix “A”), rated to 500 PSIG, make the 370A Series an ideal solution for CNG fuel gas filtration.
Quick Comparison
| Instrument Air-Gas Assemblies (1/4 - 1/2 Inch) remove | Compressed Air & Gas Assemblies (0.75 - 1 inch) remove | High Capacity Aluminum Filters (1.50 to 2 inch) remove | Filter Regulator Assemblies remove | Miniature Point-of-Use Filters remove | Brass Filter Housings remove | |
|---|---|---|---|---|---|---|
| Name | Instrument Air-Gas Assemblies (1/4 - 1/2 Inch) remove | Compressed Air & Gas Assemblies (0.75 - 1 inch) remove | High Capacity Aluminum Filters (1.50 to 2 inch) remove | Filter Regulator Assemblies remove | Miniature Point-of-Use Filters remove | Brass Filter Housings remove |
| Image | |  |  |  |  |  |
| SKU | ||||||
| Rating | ||||||
| Price | ||||||
| Stock | ||||||
| Weight | N/A | N/A | N/A | N/A | N/A | N/A |
| Dimensions | N/A | N/A | N/A | N/A | N/A | N/A |
| Additional information | ||||||
| Description | Protect your equipment and sensitive instruments from water, oil, and dirt with our high-efficiency instrument filters, engineered to remove contaminants at 99.99% efficiency down to 0.01 micron. | Our 380AHP Series delivers high-efficiency filtration in a robust, service-friendly package. Each housing is 100% machined, fully anodized, and designed for easy maintenance with a large hex base, one-piece bowl, and captured O-ring. The standard model is rated to 1500 PSIG, making it ideal for CNG, fuel gas, and compression service. | Protect sensitive equipment, dry-seal compressors, and high-volume air and gas applications with our large coalescing filter assemblies. Like their smaller counterparts, these filters utilize our advanced microfiber elements to remove up to 99.99% of contaminants at 0.01 micron. | Experience clean, dry compressed air and consistent pressure control in one smart, space-saving solution. | Protect your instrumentation and sensitive equipment from water, oil, and dirt with our high-efficiency, point-of-use miniature filters. | For air service, Headline Filters brass filter housings are precision-machined from solid brass bar stock, with durable nylon internals and a Viton seal. They are ideal for point-of-use instrument air filtration and are available in the B360 series, which comes equipped with our high-flow 80C grade coalescing filter element. This element is engineered for heavily saturated air systems, efficiently removing large volumes of liquid while providing long service life for particulate filtration. |
